Other information:
Schematic Diagrams
Terminal Function
Pin NO.
Function
Pin NO.
Function
2
RR Motor Ground
8
EPB signal 3
3
RR Motor Power
...
Removal
1.
Disconnect the battery negative terminal.
2.
Remove the intake manifold stay(A).
Tightening torque :
18.6 - 23.5 N·m (1.9 - 2.4 kgf·m, 13.7 - 17.4lb·ft)
...
